Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine

Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine

Product Details:

Place of Origin: China
Brand Name: GWELL
Certification: CE
Model Number: GWS120/GWP85

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS
Delivery Time: 90 days after all the technical requirements are confirmed
Payment Terms: L/C, T/T
Supply Ability: 200 sets/yr
Get Best Price Contact Now

Detail Information

Product Name: Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine Machine Type: Plastic Sheet Extrusion Line
Brand: GWELL Suitable Material: PLA
Width: 800-1500mm Thickness: 0.15-1.5mm
Screw Design: Single Screw/Twin Screw Country Of Origin: China
Warranty: One Year After-sales Service: Installation And Machine Debug
High Light:

Pla Sheet Extrusion Plant

,

Pla Sheet Extrusion Machine

,

Pla Sheet Extrusion Process

Product Description

Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine





(1)Machine configuration of Pla Sheet Extrusion Line

Type GWS90 single screw extruder GWS120 single screw extruder GWS85 twin screw extruder
Product width 500mm - 800mm 800mm - 1200mm 800mm - 1200mm
Product thickness 0.15mm - 2mm 0.15mm - 2mm 0.15mm - 2mm
Output 150KG/H - 200KG/H 300KG/H - 400KG/H 450KG/H - 550KG/H


Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine 0

(2) Twin-screw combination technology of Pla Sheet Extrusion Line

Years of experience in R&D and design of twin-screw configuration are optimized and combined with advanced software technology. Special double-threaded elements and unique screw combinations can realize conveying plasticization, mixing and kneading, shearing and dispersing, homogenizing, exhausting, pressure building and extrusion and various functions. Especially for the removal of crystal water inside the PLA material, it has a very high efficiency. The specially designed exhaust port does not emit material, and is free and unobstructed. It realizes low-temperature extrusion and avoids thermal degradation of PLA;

Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine 1

(3) Vacuum exhaust technology

Multi-stage forced exhaust is efficient and safe to ensure that the PLA material will not be hydrolyzed or crystallized during the melting and plasticizing process. Special three-stage vacuum exhaust technology and oil-gas separation technology, super large pumping capacity and super high vacuum, greatly reduce the viscosity reduction of PLA.pla sheet extrusion line

Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine 2





(4) Spiral flow channel technology inside the high-strength roller

The internal spiral flow channel structure design of the high-strength roller is equipped with a water temperature control system, so that the roller has precise temperature control and efficient heat transfer effects;





(5) Introduction to GWELL machine

Gwell plastic transparent sheet unit production line absorbs and digest western country advanced extrusion technology. And its main parts choose from all over the world (such as screw, barrel, roller, etc.). The energy consumption of its complete sets of equipment , intelligent, automation, safety standard, technology standard, etc., have been at or near the world standard of the product. This series of products has a number of inventions and utility model patents so that it replaces imported equipment, and has a cost-effective advantage.Its quality has reached the world's product performance, and we have a matching team of experts and process engineers to help users debug, produce high-quality products.



Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine 3





Pla Sheet Extrusion Line,Polylactic Acid Sheet Making Machine 4
