PET Sheet Making Machine of Twin Screw Thermo forming Extrusion

PET Sheet Making Machine of Twin Screw Thermo forming Extrusion

MOQ: 1 set
Price: Negotiable
Standard Packaging: STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS
Delivery Period: 90 days after all the technical requirements are confirmed
Payment Method: L/C, T/T
Supply Capacity: 200 sets/year
Detail Information
Place of Origin
China
Brand Name
GWELL
Certification
CE
Model Number
GWS90/GWS120/GWS130
Product Name:
PET Sheet Making Machine Of Twin Screw Thermo Forming Extrusion
Brand:
GWELL
Country Of Origin:
China
Suitable Material:
Virgin PET, Recycled PET, PET Flakes, PET Scraps
Width:
800-1500mm
Thickness:
0.2-1.5mm
Screw Design:
Single Screw / Parallel Twin Screw
Product Application:
Food Container,food Box,transparent Cake Box, Etc
Sheet Structure:
One Layer,two Layers, Three Layers, Multiple Layers
Color Of Sheet:
Transparent, Colored
Warranty:
One Year
After-sale Service:
Installation And Machine Debug
Minimum Order Quantity:
1 set
Price:
Negotiable
Packaging Details:
STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS
Delivery Time:
90 days after all the technical requirements are confirmed
Payment Terms:
L/C, T/T
Supply Ability:
200 sets/year
Highlight:

Twin Screw Thermoforming Extrusion

,

Thermoforming Extrusion Pet Sheet Line

,

Extruders for thermoforming sheet

Product Description

PET Sheet Making Machine of Twin Screw Thermo forming Extrusion



1. Introduction of PET sheet making machine

(1) Single screw production line for PET sheet making machine: single screw extrusion production line for PET sheet making machine is the most mature project with the most stable production at present. Generally, single extruder production line or twin-extruder production line is adopted and Gwell uses the latest technology to increase the general efficiency by 30%.The transparency of PET sheet making machine can reach optical level.

However, this model has very high requirements for raw material processing, and the PET raw material needs to be crystallized and dried. This can ensure that the produced PET sheet has no crystal points, whiteness, and poor transparency.

The main features of PET sheet making machine: impact resistance, excellent processability, good chemical resistance, and good insulation.



(2) PET sheet making machine: PET sheet making machine single-screw exhaust extrusion production line is improved from the PET sheet making machine, which increases the exhaust function, Make the material in the screw barrel easier to remove the gas and excess water in the material. This equipment is not very strict on raw material processing. It only needs to crystallize the raw materials without drying. The quality of the products produced is also very good.



(3) PET sheet making machine twin-screw exhaust extrusion production line is improved from PET sheet single-screw production equipment. The raw material processing non-crystallization, non-drying exhaust type PET sheet making machine has the advantages of low energy consumption and high efficiency. This model is a continuous improvement and upgrade product of Gwell. It has made significant improvements to the core vacuum system. The technology upgrades from the original Roots-water ring pump set to the Roots-rotary vane pump set, which can make the vacuum reach ≤10Pa. At the same time, the PET special alloy steel thin-walled roller set is used to greatly improve the cooling efficiency, thereby increase output, improve product toughness and transparency. The operating system independently written by Gwell ensures the humanization and easy operation of the equipment.PET sheet making machine



2. Model of PET sheet making machine:

Type of machine GWP75 Twin screw+GWS65 Single screw GWP85 Twin screw+GWP52 twin screw GWP95 Twin screw+GWP65Twin screw
Width of product 800mm - 1000mm 800mm - 1200mm 1000mm - 1500mm
Thickness of product 0.15mm - 2mm 0.15mm - 2mm 0.15mm - 2mm
Output 300KG/H - 450KG/H 500KG/H - 600KG/H 800KG/H - 900KG/H



Type of machine GWS90 single screw GWS120 single screw GWS150 single screw
Width of product 600mm - 800mm 800mm - 1200mm 1000mm - 1500mm
Thickness of product 0.15mm - 2mm 0.15mm - 2mm 0.15mm - 2mm
Output 150KG/H - 200KG/H 300KG/H - 400KG/H 400KG/H - 500KG/H



PET Sheet Making Machine of Twin Screw Thermo forming Extrusion 0

PET Sheet Making Machine of Twin Screw Thermo forming Extrusion 1



PET Sheet Making Machine of Twin Screw Thermo forming Extrusion 2
