ASA Extrusion Single Screw Extrusion Machinery Decorate Film Making

ASA Extrusion Single Screw Extrusion Machinery Decorate Film Making

MOQ: 1 set
Price: Negotiable
Standard Packaging: STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS
Delivery Period: 90-100 days after all the technical requirements are confirmed
Payment Method: L/C, T/T
Supply Capacity: 200 sets/year
Detail Information
Place of Origin
China
Brand Name
GWELL
Certification
CE
Model Number
GWS90,GWS120
Product Name:
ASA Decorate Film Make Machine
Machine Type:
Plastic Cast Film Extrusion Line
Brand:
GWELL
Suitable Material:
ASA
Width:
1000mm --1500mm
Thickness:
0.05mm--0.2mm
Screw Design:
Single Screw
Country Of Origin:
China
Warranty:
One Year
After-sales Service:
Installation And Machine Debug
Minimum Order Quantity:
1 set
Price:
Negotiable
Packaging Details:
STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS
Delivery Time:
90-100 days after all the technical requirements are confirmed
Payment Terms:
L/C, T/T
Supply Ability:
200 sets/year
Highlight:

ASA Single Screw Extrusion Machinery

,

asa co-extrusion

,

cast film extrusion process

Product Description

ASA Decorate film make machine,Single screw extruder , Can be customized​



1. Introduction of ASA film

ASA is a copolymerization of styrene, acrylonitrile and acrylic rubber. Technically speaking, ASA not only maintains the main characteristics of ABS, but also combines the advantages of acrylic weather resistance, so that the application of the product can be extended to outdoor use. ASA film products are made of high content of ASA rubber powder raw materials. The products have completely passed the 12,000-hour weather resistance test. The color retention performance is many times higher than that of the current co-extruded materials on the market. The uniformity of ASA film is higher than that of co-extruded material, there is no color difference of thin spots, and no waste of scraps. Therefore, the ASA cast film has become a development trend at this stage.



2. Application of ASA film

Because ASA film has good weather resistance, uniformity, extensibility and crease resistance, it is widely used in roof color steel tiles, resin tiles and plastic sheets, sheet surfaces, outdoor plastic lounge chairs, outdoor lamps and lanterns surface coating and advertising board, decorative board.



3. The equipment features of the ASA cast film production line produced by our company

(1) The whole set of equipment adopts PLC, closed-loop control so it can realize one-key speed increase and is easy to operate.

(2) The special screw design of the extruder ensures that the melting of the raw plastic material, the color of the product is uniform, and the extrusion volume is high

(3) The full-automatic mold combined with the thickness gauge can more effectively fine-tune the melt thickness deviation in the transverse width of the die, and the thickness uniformity is guaranteed to be ±10 um.

(4) The casting roll adopts the method of integral machining of the inner runner to ensure the temperature control within ±1 degree, and the rolling surface control accuracy within± 10um to ensure more accurate casting film thickness.

(5) The tension sensor and control system are used to ensure the tension control is ± 10um.

(6) A complete set of servo motors and servo controllers make the equipment run more accurately.

(7) The fully automatic cutting and rewinding machine has two functions: contact rewinding and gap rewinding. The winding tape has tension control, the adjustment range is 5-200N/M.



Gwell plastic transparent sheet unit production line absorbs and digest western country advanced extrusion technology. And its main parts choose from all over the world (such as screw, barrel, roller, etc.). The energy consumption of its complete sets of equipment , intelligent, automation, safety standard, technology standard, etc., have been at or near the world standard of the product. This series of products has a number of inventions and utility model patents so that it replaces imported equipment, and has a cost-effective advantage. The high-level transparent plate products are widely used in optics, home appliances, construction engineering, decoration, furniture, advertising, handicrafts and other industries and civil industries. Its quality has reached the world's product performance, and we have a matching team of experts and process engineers to help users debug, produce high-quality products.



4. Machine configuration:

model   GWS90 GWS120
Raw materials   ASA  ASA
Product width   1000mm  1500mm
Product thickness   0.05-0.2mm 0.05-0.2mm
Output   150-180kg/h 250-350kg/h


ASA Extrusion Single Screw Extrusion Machinery Decorate Film Making 0





ASA Extrusion Single Screw Extrusion Machinery Decorate Film Making 1








ASA Extrusion Single Screw Extrusion Machinery Decorate Film Making 2





ASA Extrusion Single Screw Extrusion Machinery Decorate Film Making 3

ASA Extrusion Single Screw Extrusion Machinery Decorate Film Making 4

Gwell Machinery is a high-tech enterprise, committed to providing customers with plastic sheet, board, film and other extrusion lines. Gwell can provide turnkey projects, such as stone paper project, EVA solar film project, PP building formwork equipment,etc. Gwell has a strong technical equipment strength and key capacity, committed to high-end product development, international market development. “Realize customer value" is the company's long-term business philosophy.The manufacturing bases of the company are located in Taicang, Suzhou, which is close to the beautiful scenery of Shanghai, Yancheng Dafeng, the hometown of Red-crowned crane, and Nantong, the hometown of Education and longevity in China. It covers a total area about 150,000 square meters. It has an annual production capacity of more than 200 extrusion lines of various types of sheet and board.
