2600mm Wide EVA Film Production Line For Solar Energy Photovoltaic Module
Product Details:
| Place of Origin: | China |
| Brand Name: | GWELL |
| Certification: | CE |
| Model Number: | GWS180 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS |
| Delivery Time: | 90 days after all the technical information is confirmed |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 200 sets/yr |
|
Detail Information |
|||
| Product Name: | 2600mm Wide EVA Film Production Line | Machine Type: | EVA Solar Film Extrusion Line |
|---|---|---|---|
| Brand: | GWELL | Suitable Material: | EVA |
| Film Structure: | Single Layer | Width: | 2600mm |
| Thickness: | 0.45mm | Winder Design: | Two Winders 1300mm+1300mm |
| Material Mixer: | Mixing Kettle | Automatic Level: | Manual Mode, Semi-automatic Mode |
| T-die: | Automatic Model, Manual Model | Thickness Control: | Closed Loop, Can Be Open Loop |
| High Light: | 2600mm Wide Eva Film Extrusion Line,2600mm Wide EVA Film Production Line,Single Layer Eva Film Extrusion Line |
||
Product Description
2600mm Wide EVA Film Production Line For Solar Energy Photovoltaic Module
1. 2600mm wide EVA Film Production line
Based on the market demand and customer's feedback, Gwell has upgraded the EVA solar film machine for many times during the past ten years. Now we have EVA solar film machine to produce 2600mm wide EVA film. And there are two winders equipped on the production line so that customers can get two rolls of 1300mm wide EVA film at the same time. Meanwhile, since the machine model is designed to be large, the output and production line speed have been increased as well. If you want to know more information, please feel free to contact me or add my whatsapp/wechat. I can show you more information, videos and photos.
2. Specification of EVA Solar Film Producing Line:
| Extruder type | GWS120 | GWS150 | GWS160 | GWS180 |
| raw material | EVA ,POE | EVA ,POE | EVA ,POE | EVA,POE |
| Product width | 2200mm, 2400mm, 2600mm | |||
| Product thickness | 0.2mm -1mm | 0.2mm -1mm | 0.2mm -1mm | 0.2mm -1mm |
| Maximum linear speed | 15m/mn | |||
| Extruder type | Co-extrusion GWS160+GWS160 | Co-extrusion GWS180+GWS160 | Co-extrusion GWS180+GWS180 |
| raw material | EVA ,POE | EVA ,POE | EVA,POE |
| layers | A,A/B/A | ||
| Product width | 2400mm,2600mm | ||
| Product thickness | 0.2mm -1mm | 0.2mm -1mm | 0.2mm -1mm |
| Maximum linear speed | 18m/min | ||
3. EVA encapsulation film production line installation
Once the production line is going to be sent to customer's factory, then customer has to consider about the space for installation and machine running. In order to get clear and qualified EVA solar film, there are some workshop standards, like the dust free level, air conditioner for room temperature and etc. Also we mentioned about the space, customers have to leave enough space not only for putting machine, also for considering about some extra space for installation and regular maintenance. All the details will be included in our manual guiding book.
