| MOQ: | 1 set |
| Price: | Negotiable |
| Standard Packaging: | STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS |
| Delivery Period: | 90 days after all the technical requirements are confirmed |
| Payment Method: | L/C, T/T |
| Supply Capacity: | 200 sets/yr |
Multiwall PP Hollow section plate extrusion line used for fruit folding boxes
1. Introduction of China Gwell Machinery Co.,Ltd.
Gwell is a professional manufacturer of plastic film, sheet and board extrusion lines. We have been in this industry for over 11 years. The first branch company was established in 2010. Now we have three production bases which are located in Jiangsu Taicang, Yancheng and Nantong. The three plants are all very close to Shanghai Port. It's convenient for customers over all the world to come and visit. If you are interested in the PP hollow section board extrusion machines, please check the following information and feel free to contact us.
Specification of PP Hollow Sheet Making Machine:
| Extruder Specification | Single screw extruder GWS120 | Single screw extruder GWS120+GWS65 | Single screw extruder GW150+ GWS90 |
| Structure of Product | Single layer A | A; A/B/A | A; A/B/A |
| Suitable Material | PP or PE | ||
| Width of Product | 800mm-1500mm | 1220mm-1500mm | 1500mm-2100mm |
| Thickness of Product | 2mm - 15mm | 2mm - 15mm | 2mm - 15mm |
| Output | 250KG/H - 350KG/H | 300KG/H - 400KG/H | 500KG/H - 600KG/H |
2. Introduction of PP Hollow Sheet Making Machine
The screw and barrel used by Gwell are optimized for processing with high-performance alloy steel, so that the whole machine has the advantages of uniform plasticization, stable extrusion, high output and long life. The main barrel is heated by a cast aluminum heater, air-cooled, and the temperature is controlled by a precision electronic control instrument. The precise shaping and calendering device, through its good adjustment function, makes the plate shape excellent. The cutting part adopts a fixed-length cutting device to ensure the precise length of the plate.
PP Hollow Sheet Making Machine is a new type of material with light weight (hollow structure), non-toxic, non-polluting, waterproof, shockproof, anti-aging, corrosion-resistant, and rich in colors. Compared with cardboard structure products, hollow boards have the advantages of moisture resistance and corrosion resistance.
PP Hollow Sheet Making Machine: PP hollow grid board has light weight, high strength, moisture resistance, good environmental protection performance and secondary processing performance, and can be processed into turnover boxes, packaging boxes, etc. It is an important product to replace carton in the future.PP Hollow Sheet Making Machine
3. Introduction of PP Hollow Sheet Extrusion Machine
GWELL's PP Hollow Sheet Making Machine relies on more than ten years of manufacturing experience. The PP Hollow Sheet Making Machine has a smooth and flat surface. The color can be changed according to the requirements. The surface of the board is coated with uv layer. The length can be set according to requirements; the width range is 800mm-2100mm; the thickness range is 2mm-15mm. The raw materials used have a wide range of shapes, and can be used in both granular and flake shapes.
