Plastic Water Stop Pvc Sheet Extrusion Line Pvc Twin Screw Extruder

Plastic Water Stop Pvc Sheet Extrusion Line Pvc Twin Screw Extruder

MOQ: 1 set
Price: Negotiable
Standard Packaging: STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS
Delivery Period: 90 days after all the technical documents are confirmed
Payment Method: L/C, T/T
Supply Capacity: 200 sets per year
Detail Information
Place of Origin
China
Brand Name
GWELL
Certification
CE
Model Number
GWC80 GWP93 GWS150
Product Name:
PVC Plastic Water Stop Extrusion Equipment Provide Installation And Commissioning
Machine Type:
Plastic Waterproof Membrane Extrusion Line
Brand:
GWELL
Suitable Material:
PVC
Width:
350mm
Thickness:
4-10mm
Screw Design:
Conical Twin Screw / Parallel Twin Screw
Country Of Origin:
China
Warranty:
One Year
After-sales Service:
Installation And Machine Debug
Minimum Order Quantity:
1 set
Price:
Negotiable
Packaging Details:
STRETCHING FILM, PLASTIC FILM PACKAGE, WOODEN CASES PACKAGE FOR KEY PARTS
Delivery Time:
90 days after all the technical documents are confirmed
Payment Terms:
L/C, T/T
Supply Ability:
200 sets per year
Product Description

PVC Plastic Water Stop Extrusion Equipment Provide Installation And Commissioning



1. Introduce of PVC water stop

PVC plastic water stop is mainly used for the foundation project which is composed of concrete in construction joints and deformation joints when concrete is poured. Such as tunnels, culverts, aqueducts,dams, liquid storage structures, underground facilities and so on. Plastic watertight zone makes full use of the elastic deformation characteristics of PVC resin in the construction joints to prevent leakage and seepage, and has the characteristics of corrosion resistance and durability.



2. Introduction of PVC Waterstop Production Equipment

(1) The production line is composed of a mixer, a conical twin-screw extruder, a mold, a cooling and setting platform, a tractor, a cutting unit, and a winding machine. With the unique raw material formula and production process, the tensile strength, elongation at break, hardness, low temperature bending and other indicators of the product meet the standard requirements.

(2) The machine can realize multiple functions in one machine, and can also be used to produce pvc door profiles and pvc window profiles.



3. Specification:

Type of extruder Conical twin-screw extruder GWC80 Parallel twin-screw extruder GWP93 Single screw extruder GWS150
Raw material PVC powder material PVC powder material PVC grain material
Width of product 350mm 350mm 350mm
Thickness of product 4mm-10mm 4mm-10mm 4mm-10mm
Output 400kg/h 500kg/h 550kg/h



Gwell plastic transparent sheet unit production line absorbs and digest western country advanced extrusion technology. And its main parts choose from all over the world (such as screw, barrel, roller, etc.). The energy consumption of its complete sets of equipment , intelligent, automation, safety standard, technology standard, etc., have been at or near the world standard of the product. This series of products has a number of inventions and utility model patents so that it replaces imported equipment, and has a cost-effective advantage. The high-level transparent plate products are widely used in optics, home appliances, construction engineering, decoration, furniture, advertising, handicrafts and other industries and civil industries. Its quality has reached the world's product performance, and we have a matching team of experts and process engineers to help users debug, produce high-quality products.



Plastic Water Stop Pvc Sheet Extrusion Line Pvc Twin Screw Extruder 0

Plastic Water Stop Pvc Sheet Extrusion Line Pvc Twin Screw Extruder 1





Plastic Water Stop Pvc Sheet Extrusion Line Pvc Twin Screw Extruder 2

Gwell Machinery is a high-tech enterprise, committed to providing customers with plastic sheet, board, film and other extrusion lines. Gwell can provide turnkey projects, such as stone paper project, EVA solar film project, PP building formwork equipment,etc. Gwell has a strong technical equipment strength and key capacity, committed to high-end product development, international market development. “Realize customer value" is the company's long-term business philosophy.The manufacturing bases of the company are located in Taicang, Suzhou, which is close to the beautiful scenery of Shanghai, Yancheng Dafeng, the hometown of Red-crowned crane, and Nantong, the hometown of Education and longevity in China. It covers a total area about 150,000 square meters. It has an annual production capacity of more than 200 extrusion lines of various types of sheet and board.
